INFORMATION
Ⅲ Press P (Fig. 5/E) to activate the INFORMATION programming
step.
1 ESPRESSO
200
PRODUCTS
Ⅲ Press the «+» or «–» key to select the required item of infor-
mation.
You can leave the INFORMATION menu any time by
pressing EXIT (Fig. 5/K).
Ⅲ Press the «+» or «–» key to select the next program step or press
EXIT (Fig. 5/K) to leave programming mode.
Under TOTAL you will find all the products made (coffee,
hot water and steam)
15. Counter
The single counter allows you to record your consumption
over a defined period of time. This counter can be reset to 0
at any point in time.
COFFEE READY
Ⅲ Press Counter (Fig. 5/D) until you hear an acoustic signal.
1 ESPRESSO
150
PRODUCT
Ⅲ Press the «+» or «–» key to select a product.
Ⅲ The display will indicate the number of times this product was
made.
Ⅲ Press EXIT (Fig. 5/K) to leave the COUNTER.
Reset counter:
COUNTER
RESET
NO
Ⅲ Press the «+» or «–» key until the display indicates
COUNTER
RESET
YES
Ⅲ Press P to confirm your selection (Fig. 5/E).
RESET
16. Maintenance
16.1 Filling the water tank
WATER TANK
FILL
Ⅲ If this message is displayed, the machine will no longer make
coffee/hot water. Refill water as described in Chapter 3.3.
The water tank should be rinsed out and filled with fresh
water daily. When using a fixed water supply system, we
recommend regularly rinsing the water tank and filling it
with fresh water.
16.2 Installing a fixed water supply system
Please refer to the operating instructions for the fixed water supply
system or contact your JURA dealer.
16.3 Emptying the coffee grounds container
The coffee grounds container collects the coffee grounds.
GROUNDS
EMPTY
Ⅲ If this information is displayed, the machine will no longer make
coffee. The grounds container needs to be emptied.
Ⅲ Carefully take out the drip tray; it is filled with water. Remove
the grounds container (Fig. 9/ A).
16.4 Emptying the drip tray
DRIP TRAY
EMPTY
Ⅲ If this information is displayed, the machine will no longer make
coffee. The drip tray needs to be emptied.
Ⅲ Carefully take out the drip tray; it is filled with water (Fig. 9/B).
16.5 Grounds bin missing
GROUNDS BIN
MISSING
Ⅲ If this message lights up, the grounds bin is not installed properly
or missing altogether.
16.6 Filling the bean tank
COFFEE READY
FILL
BEANS
The display dialog system indicates which of the two bean tanks is
empty. Fill tank with beans as described in Chapter 3.4.
The bean level is monitored electronically on the IMPRES-
SA X9. To ensure smooth operation, we recommend that you
regularly clean the bean tanks with a dry cloth. Switch the
machine off with the ON / OFF key (Fig. 5/A) before you do
so.
Ⅲ Switch the machine off with the power switch on the rear of the
machine (Fig. 15/D).
16.7 Removing stones
Ⅲ Open the programming door on the front (Fig. 4) and switch the
IMPRESSA X9 off with the ON / OFF key (Fig. 5/A).
Ⅲ Switch the machine off with the power switch on the rear of the
machine (Fig. 15/D) and disconnect it from the mains supply.
Ⅲ Open the hinged door on reverse of the machine (Fig. 10).
Ⅲ Push sliders to the rear (Fig. 10) and take the bean tank out of the
machine.
Ⅲ Remove any beans with a vacuum cleaner.
Ⅲ Insert the key (Fig. 11).
Ⅲ Now turn the key counter-clockwise until the jammed stone is
released.
Ⅲ Remove any remaining powder with a vacuum cleaner.
Ⅲ Re-install the bean tank and pull the sliders to the front before
closing the door (Fig. 10).
