17
Part 3: REPLACEMENT PARTS
DOOR SWITCH AND BLOCKS
Fig. 3.3 Part
Item No. No. Part Description Qty
1 108442 Bolt M5 x 15mm Filister Head ..................................................... 2
2 Washer ........................................................................................... 2
3 Washer ........................................................................................... 1
4 Nut................................................................................................. 1
5 C120343 Switch, Hood Activated ................................................................ 1
6 110214 Nut, Dull M6 ................................................................................. 4
7 C260219 Screw, M6 x 35 ............................................................................. 4
8 Screw ............................................................................................. 8
9 107437 Bolt, M6 x 45 ................................................................................ 4
10 107395 Block, Pivot Lower ....................................................................... 4
11 107420 Nut, Plain M6 SST........................................................................ 4
12 107393 Pin, Pivot Hood ............................................................................. 2
13 C260537 Pivot Spacer .................................................................................. 2
14 107436 Screw, M6 x 16 Fillister Head ...................................................... 2
15 107396 Block, Pivot Top ........................................................................... 2
16 C190149 Pivot Block, Hood Frame ............................................................. 4
17 331037 Handle, Hood ................................................................................ 1
