............ www.truemfg.com ............
INSTALLATION MANUAL FOR
TCGR DISPLAY CASES (REFRIGERATED BAKERY & COLD DELI) MODELS
CURVED GLASS DISPLAY CASES
- REFRIGERATED BAKERY & COLD DELI -
CONGRATULATIONS!
You have just purchased the finest commercial
refrigeration available. You can expect many years
of trouble-free operation.
TRUE FOOD SERVICE EQUIPMENT, INC.
2001 East Terra Lane • P.O. Box 970 • O’Fallon, Missouri 63366
(636)-240-2400 • FAX (636)272-2408 • INT’L FAX (636)272-7546 • (800)325-6152
Parts Department (800)424-TRUE • Parts Department FAX# (636)272-9471
TABLE OF CONTENTS
Safety Information
Safety Precautions ––––––––––––––––––––––– 1
Proper Disposal –––––––––––––––––––––––––– 2
Connecting Electricity ––––––––––––––––––––– 3
Adapter Plugs ––––––––––––––––––––––––––– 3
Installation / Operation Instructions
Ownership –––––––––––––––––––––––––––––– 4
Required Tools ––––––––––––––––––––––––––– 4
Uncrating ––––––––––––––––––––––––––––––– 4
Locating –––––––––––––––––––––––––––––––– 5
Leveling Cabinet ––––––––––––––––––––––––– 5
Electrical Instructions ––––––––––––––––––––– 6
Wire Gauge Chart –––––––––––––––––––––––– 7
Start-up –––––––––––––––––––––––––––––––– 8
Shelving Installation –––––––––––––––––––– 9-10
Installing Optional Castors –––––––––––––––– 11
Installing Optional Formica Kit ––––––––––––– 12
Maintenance, Care & Cleaning
Optional Sealing Cabinet To Floor –––––––––– 13
Cabinet Cleaning –––––––––––––––––––––––– 13
Light Bulb Replacement –––––––––––––––––– 14
Temperature Control Adjustment ––––––––––– 15
Cleaning The Condenser –––––––––––––––––– 16
Important Warranty Information –––––––––––– 17
Stainless Steel Equipment Care and
Cleaning ––––––––––––––––––––––––––––– 18-19
Warranty (U.S.A. and Canada ONLY!) ––––––– 20
TCGR-77
TCGR-50
TCGR-50-CD
3/26/07 500 SB #912628
*Spanish, German, and French versions included.
