Operation, cont’d
CrossPoint / MAV Matrix Switchers • Operation
3-4
Input and output buttons
Primary functions
Action:
Selectinputoroutputfortiebeingcreated.
Indications:
Blink:potentialtie/untie.
Lit: current tie
Amber: video and audio tie
Green: video only tie
Red: audio only tie
1
2
3
through up to
32
Secondary functions
I/O Grouping Action 1:
Input 1 and Output 1:
SelectI/O Group
mode.
Action 2/
indication:
Assign an input or output to the selected group.
Lit:Inputoroutputisassignedtotheselectedgroup.
Presets Action/
indication:
SelectapresetinPreset mode.
Lit: A preset has already been saved to this location.
Blink:Presetlocationisselectedtobesaved.
RGB Delay Indication:
CrossPoint:
Input 1 through 10:IndicatetheRGBdelay.
Input audio
level
Action/
indication:
(inputs)
Inputs:Selecttheinput’saudioforgainorattenuationadjustment.
Lit:Input’saudioisselectedforadjustment.
Indication:
(outputs)
Indicatetheinputgainorattenuationlevel.
Output audio
volume
Action/
indication:
(outputs)
Outputs:Selecttheoutput’saudioforvolumeadjustment.
Lit: Output’s audio is selected for adjustment.
Indication:
(inputs)
Indicatetheoutputvolumelevel.
Mutes Action/
indication:
Outputs: Pressandholdtomutethevideoandaudio,video,oraudiooutput.
Outputs, blink: Output is muted.
Background
illumination
Action:
Toggle between background illumination
or buttons unlit.
N
If the switcher has fewer inputs or outputs than input or output buttons,
only the buttons for which the switcher has an input or an output perform the
function of selecting and identifying that input or output.
