ZENworks® ESM 3.5 Administrator’s Manual 129
• IP - This type limits the address to 15 characters, and only containing the num-
bers 0-9 and periods (example: 123.45.6.189). IP addresses may also be
entered as a range (example: 123.0.0.0 - 123.0.0.255)
• MAC - This type limits the address to 12 characters, and only containing the
numbers 0-9 and the letters A-F (upper and lower case); separated by colons
(example: 00:01:02:34:05:B6)
Step 5: Select the ACL Behavior drop-down box and determine whether the ACLs listed should be
Trusted (allow it always even if all TCP/UDP ports are closed) or Non-Trusted (block
access)
Step 6: If Trusted, select the Optional Trusted Ports (TCP/UDP) this ACL will use. These ports
will permit all ACL traffic, while other TCP/UDP ports will maintain their current
settings. Selecting ‹None› means any port may be used by this ACL
Step 7: Click
Save. Repeat the above steps to create a new setting
To associate an existing ACL/Macro to this firewall setting:
Step 1: Select Access Control List from the component tree and click the Associate Component
button
Step 2: Select the ACL(s)/Macro(s) from the list
Step 3: The ACL behavior settings may be re-defined
Note:
Changing the settings in a shared component will affect ALL OTHER instances of this same component.
Use the Show Usage command to view all other policies associated with this component.
Step 4: Click Save
