14 Rev 0.0
INSTALLATION INSTRUCTIONS
EN
5.1 Leveling
5.1.1 Mounting the feet (only for some models)
Turn the appliance upside-down (see g. 5-01).
Tighten the nut (see ref. A g. 5-01) onto the threaded pin (see ref. B g. 5-01) of
the foot and then t the supplied washer; do this on both feet.
Screw the feet onto the appliance until the washers touch the base; the two feet
must be manually adjusted to the same height to prevent excessive di erences in
height between one foot and the other.
Put the appliance back on its feet.
TWO PEOPLE WEARING SAFETY GLOVES ARE NEEDED TO TURN THE
DISHWASHER UPSIDEDOWN.
A
B
Fig. 5-01
