SERVICE PARTS LIST
Nut w/ Lockwasher S0311
Nut, Nylon 1/2-13 S0313
Nut, Hex SS 6-32 x 5/15 S0316
Nut, NS 4-40 SS S0343
Screw SS 6-32 x 1/4 S0434
Screw SS 6-32 x 3/8 S0435
Screw SS 10-32 x 3/8 S0444
Washer SS .187 ID S0514
Washer SS .500 ID S0518
Washer Nylon .171 ID S0536
Panel Assy, Left Side S10036
Bracket, Vac (Model 9454) S10060
Harness LNC/Relay S10191
Elbow, Hopper Outlet S10394
Ballast, 7W 12V S10512
Cover, Ballast S10543
Vavle, Solenoid 120V S10658
Transformer 115/230V 25A S10709
Fuse, 1A 250V, Axial Leads S11141
Fuse Assy 1Amp S11142
Diverter, Spout S11594
Kit, Disp. Valve (for S1330) S1160
Switch, Heater
ON/OFF S1327
Valve, Disp S1330
Knob S1335
Cap, Drain S1347
Nut, Brass 61F 1/4 x 1/4 S1351
Hose Clamp S1369
Plug, Drain Tubing S1443
Whipper Motor S1728
Clevis S1755
Auger Motor S1943
Cable Mount S2012
Cable Tie S2013
Switch,
WATER LINE/PPORTABLE S2017
Stub Shaft S2042
Blower Motor S2316
Bushing, Flange ND-14 S2319
Hose Clamp S2380
Tinnerman, 1/2 OD S2558
Coil, 120V S2841
Connector S2850
Elbow, Female S2951
Nut w/ Collar, Jaco #P-PG-4 S3043
Switch,
FLUSH/DISPENSE S3091
Auger Spring (Heavy 4.7-3.3 gr) S3271
Kit, Repair Inlet Valve S3305
Plate, Regulator Mounting S3308
Base, Blender S3345
Mixing Chamber S3346
Seal S3347
Fitting, Plastic “Y” S3399
Fitting, Vend Valve S3410
Whipper Blade S3436
Hinge, Half-Loose Leaf S3448
Tubing, Drain S3461
Power Cord S3693
Strain Relief S3694
Whipper Spacer S3814
Washer, Rubber S4089
O-Ring S4211
Thermostat, Hi-Limit S5084
Overflow S5336
Inlet tube S5337
Thermostat, Temp Control S5611
Boot, Toggle Switch S6145
Sensor Board S6317
Foot Bumper (pk 10) S6334
Spacer, Hopper S6335
Slinger, Whipper S6340
Nut, Hopper Bearing S6363
Elbow S6367
Hopper Bearing, Modified S6374
Funnel S6399
Fitting, Plastic “T” 3/8 S6440
Water Line, 1/4 x 16-3/4 S6442
Waterline tubing S6522
Auger Spring (Light 2.4-4.0 gr) S6729
Cover Assy, Portable S6805
Light Bulb (Fuse Shaped) S7006
Inlet Valve S7213
Blower Housing S7430
Blower Wheel (P-18)
Header, Ribbon Cable, 4-Pin S7720
Flow Adjuster S8321
Indicator Light S8347
Transformer S8493
Auger Spring (Std 4.1-4.6 gr) S8501
Bracket, Prod Motor Mounting S8517
Switch,
HOT/COLD HOT/HOT S8539
Panel, Top Assy S8564
Tubing Assy (Model 9456) S8570
Flow Adjust Valve S8576
Stand Tube S8584
Wiring Harness (New Style) S8589
Support, Circuit Board S8626
Strain Relief S8637
Plate/Vent Tube Assy S8653
Funnel Cap S8775
Tubing, Silicone (18”) S8785
Fitting, SS “T” 1/4 NPT S8797
Kit, Relay Board Upgrade S8806
Plug S8860
Heater S8861
Fitting, Cabinet Drain S8862
Cable S8864
Probe Assy S8870
Agitator Wheel S8871
Tubing Assy (Model 9454) S8877
Tab, Faston Adapter 187 S8889
Harness, Door Light Direct S8890
Hopper Mounting Tray (9454) S8990
Label,
CLEANING INSTRUCTIONS S9097
Adjuster, Water S9184
Restrictor Flow Cap S9236
Hopper Only (Mod.9454,Rt) S9247
Hopper Only (Mod.9454,Lf) S9248
Hopper Only (Mod.9456) S9249
Harness, Door/Timer LG S9252
Bushing, Flared S9347
Block, Flow Adj Assy S9422
Membrane Switch (Mod. 9454) S9448
Membrane Switch (Mod.9456) S9449
Washer, Fiber S9489
Board, PC Relay Assy S9820
Blower, Vacuum Assy S9895
Magnet, Door S9898
Lampholder S9918
Lamp, Fluorescent S9920
Bracket, Vac (Model 9456) S9930
Tank S9964
Plate, Door Liner S9975
Panel, Right Side S9976
Hopper Mounting Tray (9456) S9984
Waterline Strainer SA 9052
Door, Plastic 83052
Nut, Hex 6-32 83393
Screw, 8-32 x 1/4 83394
Lockwasher, Internal SS #8 83395
Drip Tray Assy 83460
Door Shell, Metal 83472
Fitting Comp to FPT 83484
Fitting Comp to MPT 83485
Kit, Upgrade Tank Fitting 83598
Kit, Tank Drain 83655
Door Assy (Mod. 9454) 83663
Door Assy (Mod. 9456) 83665
Kit, Lamp/Ballast/Fuse 83756
Door Complete, Metal 9454 84118
Door Complete, Metal 9456 84119
ACCESSORIES
Faceplate, Clear S8475
Faceplate, Cappucino 83975
Faceplate, Cafe Elite 82319
3# Hopper Assy (Model 9456) S9032
5# Hopper Assy, Rt (Mod.9454) S9348
5# Hopper Assy, Lt(Mod.9454) S9349
Lid, Hopper (Model 9454) S9349
Lid, Hopper (Model 9456) S9622
Bottled Water Kit 6543
Vent Spout Assy, Portable Bottle S8351
Cap, Bottle S8352
Label, Hot Flavor Designation S8947
Flavor Label (pk 18)
Amaretto 82964
Hot Chocolate 82965
Iced 82966
Decaf 82967
White Chocolate 82968
Hazel Nut 82969
American Almond 82970
Cappucino 82971
Hot Cocoa 82972
Coffee 82973
Mocha 82974
Banana Nut 82975
French Vanilla 82976
Espresso 82977
Irish Creme 82978
Hot Cider 82979
Choc. Raspberry 82980
Vanilla Cream 82981
Sugar Free 82982
