Number Instruction Note
00
01 LED panel check All LED segments ON
02 Battery voltage check ”12” in range between 8,5 - 18 V DC.
“Lo” or “hl out of range
03 Air temperature Value in °F in range, “hl” or “Lo” out of range, “-- sensor faul
t
sensors, freezer + fridge
04 Surface temperature Value in °F in range, “hl” or “Lo” out of range, “-- sensor faul
t
sensors, freezer + fridge
05 Door switches status ”OP” open, “CL” closed
06 Turn AC heater ON ”ON” turned on, “no AC” problem
07 Turn fridge heater ON ”ON” turned on, “-- problem
08 Turn freezer heater ON ”ON” turned on, “-- problem
09 Turn drain heater ON ”ON” turned on, “-- problem
10 Turn door heater ON ”ON” turned on
11 Turn fridge fan ON ”ON” turned on, “-- problem
12 Turn freezer fan ON ”ON” turned on, “-- problem or “bL” blocked
13 Turn gas ignition system ON ”FL” turned on flame, “l9” sparking, “-- problem
SERVICE MODE
Service mode is intended as a tool for service personnel only in order to perform diagnostic troubleshooting.
1. Before entering service mode, switch off the refrigerator with the ON/OFF key.
2. To enter service mode, press and hold SET key, then press ON/OFF key.
3. Press SET key to toggle the list of functions step by step.
