Installation Instructions
To Adjust the Oven Door Angle
The door bottom hinge can be adjusted to alter
the angle of the door.
Loosen the bottom hinge fixing screws and
use the notch and a flat bladed screwdriver to
move the position of the hinge to set the hinge
position.
Retighten the hinge screws.
Effect of hinge adjustment – exaggerated for clarity
Centre line of hinge pin
Oven door omitted for clarity
Installing the flue grille
The flue grille is packed separately.
The larger of the holes along the sides are for
screwdriver access and should face to the rear.
Use the screws and nuts supplied to hold the
grille in place.
View from above
Clip the flexible extensions of the oven flues to
the flue grille using the clips provided inside the
flue grille.
View from below
