Installation Instructions
Follow these procedures to remove appliance
for servicing:
The range is very heavy. Take great care. We
recommend two people maneuver the range.
Ensure that the floor covering is firmly attached,
or removed to prevent it being disturbed when
moving the range around. You will need the
leveling tool.
Pull the drawer out to its furthest point.
Lift up the ends of the plastic clips (one each
side) to release the catches holding the drawer
to the side runners and at the same time pull the
drawer forward and away from the side runners.
For safety’s sake push the drawer runners back
out of the way. Put the drawer somewhere safe
- do not refit it until you have finished, you will
need access to the area behind the drawer.
Fit the leveling tool on the rectangular adjuster
as shown below.
Lower the front roller by turning the leveling tool
clockwise until the front feet are just clear of the
floor.
Slide range forward to disengage the range from
the anti-tip bracket.
Shut off the gas supply and disconnect electrical
supply to appliance. Disconnect gas supply
tubing to appliance and unplug the electrical
supply cord.
Reverse procedure to reinstall. If gas line has
been disconnected, check for gas leaks after
reconnection.
NOTE: A qualified person should disconnect
and reconnect the gas supply.
The service engineer MUST follow installation
instructions provided with the gas appliance
connector and the warning label attached to the
connector.
If your range is removed for any reason, make
sure the anti-tip device is re-engaged properly
when the range is replaced. Failure to take this
precaution could result in tipping of the range
and cause injury.
