LIGHT
#125-01-0311
orange
blue
black
white
Overhead Installation
Contactor
#125-01-1001
Term Block
POWER
#125-01-0311
N
L3
L2
L1
G
S
L
Sensor
1
L
Sensor
2
Individual Hot Food Well
1600W~240V
* #225-01-330 Snap-On T-Stat #20N11T002-L250
ON:183°F / OFF: 210°F
~208/240V-3Ø-60Hz
T-Stats have to be at each end of the case next to outer gas spring
hinge to protect O-Ring from overheating.
L
L
HE-01-46", 1400W~240V
(wells)
L
H1
L1
L2
H2
P
black
10 AWG
10 AWG
10 AWG
WH3-120-164
Ballast
(2) F28T5/TL830
L
Sensor
3
L
Loads, amp
208 V 240 V
L1
L2
L3
16.5
19.2
16.5
19.2
Note: case must be grounded
11.4
13.9
ASH, ESH/S, RGSH-L/S, RGSHS - Combo
W6000019
Hot Food Cases
4' Case / APW wells
