A-5
PVS 204SA Switcher • Reference Material
PRELIMINARY
Part Numbers and Accessories
These items are included in each order for an PVS 204SA switcher:
Included parts
Included parts Replacement
part number
PVS 204SA switcher 60-800-01
Rubber feet (4)
12 VDC, 3 A external power supply, (1)
5-pole, 3.5 mm captive screw connector, (1) 10-703-12LF
3-pole, 3.5 mm captive screw connector, (1) 10-703-11LF
2-pole, 3.5 mm captive screw connector, orange (1) 10-762-10LF
2-pole, 5 mm captive screw connector, (1)
PVS 204SA User’s Manual
Tweeker
Accessories
Accessory Part number
PVT Twisted Pair Transmitters
Architectural Adapter Plate Models
PVT CV AAP, composite video transmitter
PVT RGB AAP, RGB video transmitter
70-579-0x
70-580-0x
Decora Wall Plate Models
PVT CV D, composite video transmitter
PVT RGB D, RGB video transmitter
70-579-0x
70-580-0x
Rack Mounted Transmitters
PVT CV, composite video transmitter
PVT RGB CV, RGB and composite video transmitter
70-579-0x
70-580-0x
MediaLink Controllers
MLC 52 RS VC, IR and RS control, with volume control
60-745-12
MLC 52 RS, IR and RS control 60-744-12
MLC 104 IP Plus, with IP Link 60-818-xx
PMK 450, Pole Mount Kit 70-618-03
PCM 240, Projector ceiling mount 60-772-03
UPB 25, Universal projector mounting bracket 60-773-03
VCM 100 AAP, Volume and mute controller, AAP model 70-396-xx
VCM 100 MAAP, Volume and mute controller, mini AAP model 70-397-xx
VC 50, Volume controller wall plate 70-532-02
MSR 6, mini stereo plug to RCA audio adapter 26-592-01
MLP 101 D, mic to line preamplier, Decora wall plate model 60-822-x2
