252 Symbologies
MX6 Reference Guide E-EQ-MX6RG-E-ARC
UPCA
Syntax UPCA=p1,p2,p3,p4,p5,p6,p7
Example UPCA=1,0,0,0,0,0,0
Pn Default Valid Description
1 1 1 enable 0 disable Decode UPCA barcode
2 0 1 enable 0 disable Transmit check digit
3 0 1 enable 0 disable Transmit number system
4 0 1 enable 0 disable Transmit 2-digit addenda
5 0 1 enable 0 disable Transmit 5-digit addenda
6 0 1 enable 0 disable Only decode barcodes with 2- or 5-
digit addenda
7 0 1 enable 0 disable Insert space between code and
addenda
Note: An EAN 13 decoding algorithm will also decode UPCA labels. For correct operation,
either disable the EAN 13 symbology when using UPCA labels or configure the EAN 13
settings to match the UPCA settings.
UPCE0
Syntax UPCE0=p1,p2,p3,p4,p5,p6,p7,p8
Example UPCE0=1,0,0,0,0,0,0,1
Pn Default Valid Description
1 1 1 enable 0 disable Decode UPCE0 barcode
2 0 1 enable 0 disable Transmit check digit
3 0 1 enable 0 disable Transmit number system
4 0 1 enable 0 disable Expand version E to 12-digit UPCA
format
5 0 1 enable 0 disable Transmit 2-digit addenda
6 0 1 enable 0 disable Transmit 5-digit addenda
7 0 1 enable 0 disable Only decode barcodes with 2- or 5-
digit addenda
8 0 1 enable 0 disable Insert space between code and
addenda
Note: UPCE0 and UPCE1 must be configured identically for correct operation.
UPCE1
Syntax UPCE1=p1,p2,p3,p4,p5,p6,p7,p8
Example UPCE1=1,0,0,0,0,0,0,1
Pn Default Valid Description
1 1 1 enable 0 disable Decode UPCE1 barcode
2 0 1 enable 0 disable Transmit check digit
3 0 1 enable 0 disable Transmit number system
4 0 1 enable 0 disable Expand version E to 12-digit UPCA
format
5 0 1 enable 0 disable Transmit 2-digit addenda
6 0 1 enable 0 disable Transmit 5-digit addenda
7 0 1 enable 0 disable Only decode barcodes with 2- or 5-
digit addenda
8 0 1 enable 0 disable Insert space between code and
addenda
Note: UPCE0 and UPCE1 must be configured identically for correct operation.
