Programs 75
E-EQ-MX6RG-E-ARC MX6 Reference Guide
Add
Tap this button to manually add a network to the Configured Networks list
if
• the access point does not broadcast its SSID or
• you are pre-configuring the client for an access point that is not currently
in range.
Remove Tap this button to remove a selected network in the list.
Properties
Tap this button to review the properties of a network selected in the list.
This button opens the same network configuration screen as the Add button
does; use it to edit network configuration properties.
Protocol Tab
Figure 4-10 Protocol Tab
Protocol Options
Authentication Timeout
The period the radio will wait to receive a response from the
access point. The default is 30 seconds.
Held timeout
The length of time the client will remain in the held state after
failing authentication. The default is 60 seconds.
Start timeout
The period of time the client will remain in the connecting state
before restarting from lack of response. The default is 30 seconds.
Number of start attempts
Before the client gives up. It defaults to the authenticated state
although there is no network connectivity. The default is 3 tries.
Interface Options
Display EAP
Notifications
Enabled. This option allows informational messages from the
access point to be displayed on the screen.
Renew IP Address
Enabled. DHCP is used to obtain an IP address immediately after
authentication.
