ASSEMBLE BURNERS,
CHECK IGNITION
Assemble burner as shown.
CAUTION: Do not operate the burner without
all burner parts in place.
Place the burner heads on the burner bases
matching the letters. Place the caps on the heads.
Make sure that the heads and caps are placed on the
correct size burner. The
burner heads and burner
bases are labeled A, B and
C to aid reassembly. There
is one small (A), two
medium (B) and one large
(C) head and cap.
Make sure the notch in the burner head is positioned
toward the electrode. Rotate the burner head around
the burner base until it is level and securely seated.
Place the grates over the burners.
Check for proper ignition:
• Push in one control knob and turn to LITE position.
• The igniter will spark and the burner will light; the
igniter will cease sparking when the burner is lit.
• First test may require some time, while air is
flushed out of the gas line.
• Turn knob to OFF.
• Repeat the procedure for each burner.
INSTALL DOWNDRAFT FILTER,
VENT GASKET AND VENT GRILLE
Do not operate the vent without the filter in place.
• Place the filter diagonally through the vent
opening.
• Make sure it rests, at an angle, on the supports in
the vent opening.
• Fit the vent grille gasket around the edge of the
downdraft vent opening. Make sure the front of the
gasket is installed toward the front of the cooktop.
• Carefully place the vent grille onto the gasket on
the downdraft opening.
CHECK OPERATION OF DOWNDRAFT
• Turn the vent fan speed control to HI, MED and
LO to make sure all speeds operate correctly.
