AJ-44C Series Technical Manual 7610-001-76-22
Issued: 03-21-2006 Revised: N/A
SECTION 2: INSTALLATION/OPERATION INSTRUCTIONS
GAS CONVEYOR HOSE INSTALLATION (CONTINUED)
45
TYPICAL RECIRCULATING WATER HOOK-UP
FOR ALL GAS HEATED CONVEYORS
HOOKUP WHEN GAS BOOSTER HEATER
IS LOCATED TO THE
RIGHT OF THE
DISHMACHINE
HOOKUP WHEN GAS BOOSTER HEATER
IS LOCATED TO THE
LEFT OF THE
DISHMACHINE
CONNECTION HOSES ARE CUT TO LENGTH DURING INSTALLATION.
(ENOUGH HOSE IS PROVIDED TO LOCATE THE GAS BOOTER HEATER APPROXIMATELY 9 FEET
AWAY FROM THE DISHMACHINE. ADDITIONAL HOSE MUST BE ORDERED IF A GREATER DISTANCE
IS REQUIRED. DISTANCES GREATER THAN 20 FEET AWAY CAN AFFECT THE HEATING PERFORMANCE
OF THE UNIT)
* HOSES MARKED A IN THE ABOVE ILLUSTRATIONS CONNECT TO THE INLET WATER CONNECTION OF THE GAS BOOSTER HEATER
** HOSES MARKED B IN THE ABOVE ILLUSTRATIONS CONNECT TO THE OUTLET WATER CONNECTION OF THE GAS BOOSTER HEATER
