5. Click the Firmware Upgrade link.
6. Click the Browse button. A Choose File to Upload dialog box appears.
7. Navigate to the folder where you saved the firmware upgrade file. Select the file.
ATTENTION: The firmware file must have an .s19 extension. Other file types can
cause the switcher to stop functioning.
NOTES:
• When downloaded from the Extron website, the firmware is placed in a
subfolder of:
• Windows 7 or Windows 8: C:\Program Files (x86)\Extron\Firmware.
• Older versions: C:\Program Files\Extron\Firmware.
• The original firmware is permanently available on the switcher. If the attempted
firmware upload fails, the switcher reverts to the factory-installed firmware.
8. Click the Open button.
9. Click the Upload button. The firmware upload may take a few minutes.
File Management Tab
File Management Page
To delete files such as user-supplied HTML pages from the switcher or to upload your
own files to the switcher, click the File Management tab. The switcher downloads the file
management HTML page (see figure 90).
Figure 90. File Management Page
NOTE: The files listed in figure 90 are shown for example only and may not be present
on your switcher.
