I/O Controls
NOTE: See Front Panel Operations, beginning on page 40 for detailed descriptions
of the following operations.
Primary functions
Action Select video Select audio
Indication Green: selected Red: selected
RGBHV
or
VIDEO AUDIO
Secondary functions
Front panel
locks
Action 1 With Enter, select Lock mode 2 or toggle
between mode 0 and mode 2.
Action 2 Select Lock mode 1 or toggle between mode 2
and mode 1.
RGB Delay Action/
indication
Select RGB Delay mode.
Blinks green.
Resets Action 1 Perform a system reset.
Port
configuration
Action Select RS-232. Select RS-422
Indication Blink: selected Blink: selected
Audio Action Select Audio mode.
You must specify video, audio, or both when you are creating or viewing a configuration.
This is done with the RGBHV button (CrossPoint switchers) or Video button (MAV Plus
switchers) (g) and Audio (h) buttons.
g RGBHV (CrossPoint) button or Video (MAV Plus) button — The RGBHV
(CrossPoint switchers) or Video (MAV Plus switchers) button has one primary function
(❏) and five secondary functions (•):
❏ Selects and deselects video for a configuration that is being created or viewed and
lights green to indicate that video is available for configuring or for viewing.
• With the Enter button and Audio button, selects between front panel locks (Lock
mode 2 and Lock mode 0).
• With the Audio button, commands the front panel system reset.
• (CrossPoint switchers) Selects the RGB delay mode, in which you can set the
RGB delay.
• Selects the RS-232 protocol for the rear panel Remote port in Serial Port Selection
and Configuration mode and indicates the selection.
CrossPoint and MAV Series Matrix Switchers • Operation 38
