Care and Cleaning
48
Take particular care not to damage the inner surface of the door inner glass that is coated
with a heat reflective layer.Do not use scouring pads,or abrasive powder,which will
scratch the glass. Ensure that the glass panel is not subjected to any sharp mechanical
blows.
Stubborn stains can be removed by using a fine steel wool pad.
For slight soiling the inner glass
panel may be cleaned, while still warm,without removing it from the door.After cleaning,rinse
and dry with a soft cloth.
CLEANING THE DOORS
SIDE OPENING DOORS
Cleaning the door glass is the same as the drop down doors,except take care to support the
weight of the inner glass when removing and refitting.
DROP DOWN DOORS
Remove the door inner glass as follows.
1. Open the door fully and unscrew the two screws securing the glass panel so that the
securing brackets can be turned.There is no need to remove the screws completely.
2. Turn the brackets so that the glass can be removed and cleaned at the sink (Fig.1).
3. The inside of the outer door glass can now be
cleaned while still fitted to the cooker.
NEVER OPERATE THE COOKER WITHOUT THE INNER DOOR GLASS IN
POSITION.
Refit the door inner glass as follows.
1. NOTE:The inner door glass has a special reflective coating on one side.Replace the
door inner glass so that the statement: “IMPORTANT THIS FACE TOWARDS THE
OVEN” can be read from the inner side of the door.
2. Turn the two securing brackets back to their original
position to retain the glass and tighten the screws
(Fig.2.).
Glass
Fig. 1.
Fig. 2.
Glass
