Please check the following before calling for service:
Place one cup of water in a glass measuring cup in the oven and close the door securely.
Operate the oven for one minute at HIGH 100%.
A Does the oven light come on? YES _______ NO _______
B Does the cooling fan work? (Put your hand over the rear ventilating openings.) YES _______ NO _______
C Does the turntable rotate? (It is normal for the turntable to turn in either
direction.)
YES _______ NO _______
D Is the water in the oven warm? YES _______ NO _______
If “NO” is the answer to any of the above questions, please check electrical outlet, fuse and/or circuit breaker. If they
are functioning properly, CONTACT YOUR NEAREST DACOR AUTHORIZED SERVICER.
If the time appearing on the display is counting down very rapidly, check Demonstration Mode on page 21 and cancel.
Specifications
AC Line Voltage: Single phase 120V, 60Hz, AC only
AC Power Required: 1500 Watts, 13.0 amps.
Output Power:* 1100 Watts
Frequency: 2450 MHz
Outside Dimensions: 24"(W) x 13
3
/
8
"(H) x 19
1
/
8
"(D)
Cavity Dimensions: 17
3
/
8
"(W) x 10
1
/
2
"(H) x 18
5
/
8
"(D)
Oven Capacity:** 2.0 Cu. Ft.
Cooking Uniformity: Turntable system, diameter 16"
Weight: Approx. 46 lb
* The International Electrotechnical Commission’s standardized method for measuring output wattage. This test
method is widely recognized.
** Internal capacity is calculated by measuring maximum width, depth and height. Actual capacity for holding food
is less.
In compliance with standards set by:
NHW – Department of National Health and Welfare of Canada.
FCC – Federal Communications Commission authorized.
DHHS – Complies with Department of Health and Human Services (DHHS) rule, CFR, Title 21, Chapter I,
Subchapter J.
– This symbol on the nameplate means the product is listed by Underwriters Laboratories, Inc. for use in USA
or Canada.
Service Call Check
