Installation instructions
=
=
Dotted line showing the position
of the range when installed
ANTI-TIP STABILITY
DEVICE FIXING
Anti-tip stability
device
Rear left
feet of range
11” 11/16
(297 mm)
YOU MUST USE STABILITY
ANTI TIP BRACKET TO
PREVENT UNIT FROM
TIPPING.
Anti-tip stability device installation instructions
1
the anti-tip bracket has to be attached as shown on figure below (only rear left side), it has to be
fixed on the floor OR on the rear wall by no. 4 (four) suitable screws (not supplied). Alternatively
the anti-tip bracket can also be fixed on the floor AND on the rear wall by no. 8 (eight) suitable
screws (not supplied).
2
After fixing the anti-tip bracket, slide range into place. Be sure the rear left foot slides under the
anti-tip bracket attached.
