System Administrator’s Guide U42252-J-Z915-1-76
NSR-ORA and NetApp Configuring NSR-ORA
The configure_networker script provides the choice between the following three
scenarios for the backup of NetApp filers:
Scenario 1: Three Backups per Day
In this scenario NetWorker performs three backups per day: At 12:00 h and
16:00 h a snapshot backup is performed. At 23:50 h another snapshot with an
additional tape backup is started.
Three NetWorker groups are generated automatically:
one group for tape backups:
Interval: 24 h
Level: full
Start: 23:50
Name: <ORACLE_SID>_NDMP
two groups for pure snapshot backups:
Interval: 24 h
Level: 1
Start: 12:00 and 16:00 respectivly
Name: <ORACLE_SID>_SNAP1 and <ORACLE_SID>_SNAP2 respec-
tivly
Scenario 2: Two Backups per Day
In this scenario NetWorker performs two backups per day: At 12:00 h a
snapshot backup is performed. At 23:50 h another snapshot with an additional
tape backup is started.
Two NetWorker groups are generated automatically:
one group for tape backups:
Interval: 24 h
Level: full
Start: 23:50
Name: <ORACLE_SID>_NDMP
one group for pure snapshot backups:
Interval: 24 h
Level: 1
Start: 12:00
Name: <ORACLE_SID>_SNAP
