13
VARIETY STEAMER
P/N 1010745 Rev. G 03/06
UP
DOWN
PROGRAM SINGLESHOT
1 2 3 4
SHO T
Figure 6. SHOT Mode on Menu 1
UP
DOWN
PROGRAM SINGLESHOT
1 2 3 4
00: 10
Figure 7. Programming Mode SINGLE SHOT Button
Used for Saving All Changed Settings.
CYC (Total Cycle Time)
1. Turn the Rocker Switch (power On/Off) to ON
(Figure 3). Allow 30 minutes to preheat the unit.
NOTE: During preheating, the display will flash
“LOW”. When unit reaches operating temperature,
the display shows the factory preprogrammed
(default) time in minutes/seconds (Figure 7) and the
active channel indicator light will be on.
2. Press the Program button to change the control
from OPERATION to PROGRAM mode. CYC
will appear in the display for a moment. Select
a Menu Channel (1 thru 4), making the selected
channel the active channel.
NOTE: If no change is made withing 10 seconds
at any time during the programming process, all
changes made up to that point are stored in memo-
ry and the control reverts to OPERATION mode.
3. Press the UP or DOWN arrow buttons to change
the total cycle time in minutes (Figure 7).
4. Press the PROGRAM button again, then use the
UP or DOWN arrow buttons to change the total
cycle time in seconds.
5. When finished, either:
a.) Press the selected menu channel button to
store the changes; pressing this again will start
the steam cycle.
OR
b.) Select another menu channel for change and
repeat steps 3 & 4. Changes made to previous
channels will automatically be stored.
RATE (Shot Interval Time)
6. While in Program mode (press the PROGRAM
button if not in this mode), press both the UP and
DOWN arrow buttons simultaneously. RATE will
appear in the display for a moment (Figure 5).
7. Use the UP or DOWN arrow buttons to change
the RATE setting in seconds.
8. Press the PROGRAM button again, then use the
UP or DOWN arrow buttons to change the rate
time in minutes.
SHOT (Steam Shot Time)
9. Press the PROGRAM button again and SHOT
will appear in the display for a moment (Figure 6).
UP
DOWN
PROGRAM SINGLESHOT
1 2 3 4
RAT E
Figure 5. RATE Mode on Menu 1
UP
DOWN
PROGRAM SINGLESHOT
1 2 3 4
CYC
Figure 4. CYC Mode on Menu 1
10. Use the UP or DOWN arrow buttons to increase
or decrease the time.
11. Press the selected channel button to store the
changes (Figure 6) or press another channel but
-
ton to store the changes and select a new chan-
nel.
12. Repeat steps 1 - 11 for any of the other Menu
Channels.
NOTE: The SINGLE SHOT
button may be pressed
at anytime during programming to store any chang-
es made and execute a fixed single shot of 0.70
second.
Minutes
Seconds
PROGRAMMING (continued)
