VARIETY STEAMER
P/N 1010745 Rev. G 03/06
REPLACEMENT PARTS (continued)
Item Part Description Qty.
No.
Item Part Description Qty.
No.
1 0011539 Top Housing Assy. (Jumbo) 1
2 7000404 Generator Manifold (incl. #66 & 67) 1
3 0200187 O-Ring 1
4 0020947 Drip Tray Assy. 1
5 7000293 Generator, (208V) 5000w 1
7000295 Generator, (230V) 5000w
7000375 Generator (230V) 3500w
(for MFG # 9100720 only)
6 2020104 Drain Tube 1
7 7000297 Insulation 1
8 0501139 Retainer, Generator 2
9 0021040 Channel, Lock Lever Support 1
10 2100138 Ball Knob 1
11 0021038 Lever Support 1
12 2190102 Teflon Tube 1
13 2000214 Tube SS 1/4” 1
14 4040145 Solenoid 1
15 200K127 Inlet Tube Kit 1
16 208K106 Quick Disconnect Body 1
17 7000139 Quick Disconnect Insert 1
18 0010584 Inlet Hose Assy. (incl. #17 & 68) 1
19 0700479 Power Cord (L6-30P) 1
Mfg. No. 9100700
0700453 Power Cord (CEE 7/7 plug)
Mfg. No. 9100720
0700588 Power Cord (IEC-309 plug)
Mfg. No. 9100710)
20 7000403 Solid State Relay Kit (Incl. #21) 1
21 4050232 Heat Sink 1
22 4010192 Board, Switch PC 1
23 0503776 Cover, Main Housing 1
24 1001058 Label, Control Panel 1
1001214 Label, Viagio Control Panel 1
(Mfg. No. 9100712 & 714 only)
25 0011370 2” Leg 4
(Incl. No. 26) 1
26 2100109 Rubber Foot, Leg 4
27 4010137 Rocker Switch, Power On/Off 1
28 0020946 Panel, Bottom 1
29 7000319 Transformer, 115/230V-24V 1
30 0700591 Wire Set (not shown) 1
31 2140116 Petrol Gel (not shown) 1
32 0021244 Control Panel 1
33 7000294 Control Board 1
34 7000344 Hi-limit Thermostat Kit 1
**(See NOTE below)
35 2120171 Front Leg Spacer 2
36 0021041 Main Housing 1
37 0020958 Spray Tube 1
38 0502669 Diffuser 1
39 2100119 Handle 2
40 2100240 Handle Guard, Black 2
41 0503851 Basket 2
42 338P102 Bolt, Square Neck,3/8-16 x 3/4” SS 2
43 0011502 Large Basket Assy. (Jumbo) 2
(Incl. 39, 40, 41 & 42)
44 406K006 Terminal Block, 3-Pole 1
45 0400315 Strain Relief 1
46 308P143* Nut, Hex, KEPS, #8-32 1
47 304P105* Nut, Hex, KEPS, #4-20, Zinc 1
48 310P120* Screw, Machine, #10-32 x 5/8” 1
49 308P103* Screw, Machine, #8-32 x 1/4” 1
50 0021039 Lock Lever Weldment
51 325P169 Bolt, Shoulder, 5/16 x 1/2” 1
52 212P120 Spacer, .437” O.D. x .340 I.D. 1
53 325P154 Washer, Helical Spring Lock, 1/4” 1
54 325P102 Nut, Hex, 1/4-20 1
55 212P118 Washer, Flat, SS 1
58 325P109* Bolt, Hex Hd., 1/4-20 x 1/2” 1
59 325P104* Washer, Flat, 1/4” 1
61 4050214 Type “K” Thermocouple 1
62 1001053 Cleaning Label 1
63 204P114* Female Elbow 1/4” Tube 1
64 2040126 Nut & Sleeve Assy. 1/4” 2
65 0011071 Lock Lever Assy.
(Incl. 9, 50, 51, 52, 53, 54, & 55) 1
66 2170115 Plunger Valve 1
67 0021474 Plunger Weldment 1
68 See page 16 for Strainer Parts identification. 1
* Only available in packages of 10.
** NOTE: VS-350 units manufactured with serial
numbers 0210XXXX and prior were manufac-
tured with an external manual resettable capillary
bulb Hi-Limit Thermostat. If this type of Hi-Limit
Thermostat should require replacement, it must be
replaced with a bi-metal type (P/N 7000344) and
retrofitted into unit.
