VARIETY STEAMER
8
P/N 1010745 Rev. G 03/06
CAUTION
All electrical connections must be in accordance
with local electrical codes and any other appli-
cable codes.
WARNING
ELECTRICAL SHOCK HAZARD.
FAILURE TO FOLLOW THE INSTRUCTIONS IN
THIS MANUAL COULD RESULT IN SERIOUS
INJURY OR DEATH.
• Electrical ground is required on this appliance.
• Do not modify the power supply cord plug. If
it does not fit the outlet, have a proper outlet
installed by a qualified electrician.
• Do not use an extension cord with this appli-
ance.
• The unit should be grounded according to
local electrical codes to prevent the possibil-
ity of electrical shock. It requires a grounded
receptacle with separate electrical lines, pro-
tected by fuses or circuit breaker of the proper
rating.
• Check with a qualified electrician if you are in
doubt as to whether the appliance is properly
grounded.
Tubing-1/4"IDPVC(2)
Manifold/Regulator
Assembly
#8BracketScrews(3)
Elbow,QuickDisconnect-1/4"(3)
Cold
Water
Flow
Shutoffvalve(notsupplied)
InletHose&StrainerAssy.(supplied)
Figure 2A. Connecting Dual Manifold Water Pressure Regulator (P/N 7000235)
Drain
Connect the black drain tube (Figure 8) to the drip tray
by pressing the tub onto the drain pipe at the bottom of
the drip tray. Place the other end of the tube in a drain
or collection pan.
Electrical
1. Place the unit on a sturdy, level table or other
work surface. Be sure the Rocker Switch (Power
On/Off) is in the OFF position before proceeding.
2. Connect the unit to the power supply.
CAUTION
Water pressure must not exceed 30 psi (2.1 kg/
cm
2
or 207 kPa). Higher water pressures may
cause poor performance or flooding. To reduce
water pressure, install a water pressure regulator,
and set water pressure to 20-25 psi (1.4-1.7 kg/
cm
2
or 138-172 kPa).
!
W
A
R
N
I
N
G
1
8
M
I
S
U
S
E
O
F
P
R
O
D
U
C
T
M
A
Y
C
A
U
S
E
P
E
R
S
O
N
A
L
I
N
J
U
R
Y
.
R
E
A
D
A
S
M
E
I
N
S
T
A
L
A
T
I
O
N
/
O
P
E
R
A
T
I
N
G
I
N
T
R
U
C
T
MADEIN USA IMI
R91G-24K-NLN
INLET 150PSIG MAX
OUTLET 125PSIGMAX
To
Steamers
Pressure
Adjustment
knob
Inlet Water
Supply
