IMPORTANT:
• Installer: In the interest of safety and to minimize problems, read these installation instructions completely and carefully before you
begin the installation process. Leave these installation instructions with the customer.
• Customer: Keep these installation instructions for future reference and the local building inspector’s use.
All specifications subject to change without notice. Dacor
®
assumes no liability for changes to specifications.
© 2013 Dacor, all rights reserved.
Important Safety Instructions .....................................................1
Important Information About Safety Instructions.........................1
Safety Symbols in this Manual ...................................................1
General Safety Precautions ........................................................2
Product Specifications ................................................................3
Electrical Requirements (Except models ending with -C) ..........3
Electrical Requirements (Models ending with -C) ......................3
Product Dimensions ....................................................................4
Installation Specifications ...........................................................5
Cabinet Layout ............................................................................5
Installation Instructions ............................................................... 8
Verify the Package Contents ......................................................8
Installing the Anti-Tip Bracket .....................................................8
Backguard Installation ..............................................................10
Raised Vent Installation ............................................................10
Removing the Oven Door .........................................................10
Electrical Connection ................................................................10
Installing the Range .................................................................. 16
Re-installing the Oven Door .....................................................16
Verifying Proper Operation .......................................................17
Customer Service Information
If You Need Help...
If you have questions or problems with installation, contact your
Dacor dealer or the Dacor Customer Service Team. For repairs
to Dacor appliances under warranty call the Dacor Distinctive
Service line. Whenever you call, have the model and serial
number of the appliance ready. The model and serial number are
printed on the product data label.
Dacor Customer Service
Phone: (800) 793-0093, extension 2813 (U.S.A. and Canada)
Monday — Friday 6:00
a.m. to 5:00 p.m. Pacific Time
Web site: www.dacor.com
Dacor Distinctive Service (for repairs under warranty only)
Phone: (800) 793-0093, extension 2822 (U.S.A. and Canada)
Monday — Friday 6:00
a.m. to 5:00 p.m. Pacific Time
Product Data Label Location
The product data label can be seen through the grill below the
control panel, on the right side.
Model Identification
Product data label
(view through right side
of grate with flashlight)
Model Configuration* Handle Type Electrical Connection**
RR30NS
Freestanding, (full size side panels),
6-inch backguard standard
Mounted on
outside of door
Power cord not included. Not for
installation in Canada.
RR30NS-C
Freestanding, (full size side panels),
6-inch backguard standard
Mounted on
outside of door
Cord connected, for installation in Canada
and U.S.A., where local codes permit.
RR30NFS
Freestanding, (full size side panels),
6-inch backguard standard
Flush handle,
integrated in door
Power cord not included. Not for
installation in Canada.
RR30NFS-C
Freestanding, (full size side panels),
6-inch backguard standard
Flush handle,
integrated in door
Cord connected, for installation in Canada
and U.S.A., where local codes permit.
RR30NIS
Built-in/Slide-in (3” removable side
panels), backguard optional
Mounted on
outside of door
Power cord not included. May be installed
in Canada and U.S.A.
RR30NIS-C
Built-in/Slide-in (3” removable side
panels), backguard optional
Mounted on
outside of door
Cord connected, for installation in Canada
and U.S.A., where local codes permit.
RR30NIFS
Built-in/Slide-in (3” removable side
panels), backguard optional
Flush handle,
integrated in door
Power cord not included. May be installed
in Canada and U.S.A.
RR30NIFS-C
Built-in/Slide-in (3” removable side
panels), backguard optional
Flush handle,
integrated in door
Cord connected, for installation in Canada
and U.S.A., where local codes permit.
* See page 4 for further details.
**See page 3 for further details.
