Setting Oven Controls
CONTROL PAD FUNCTIONS
Read the instructions carefully before using the oven. For satisfactory use of your oven, become familiar with the various
functions of the oven as described below.
To activate the touch control, you just have to touch the pad with a nger. Take care to have a good contact be-
tween the nger and the touch pad. Long nails can make the activation dicult. It is a good idea to clean the control
panel after each use or as soon as possible after a spill, boil over or spatter because some ionic or salty ingredients as
ketchup, tomatoes sauce, etc. can operate the control. Before cleaning the control panel it is recommended to turn on the
control lockout feature.
The time of day rst be set in order to operate the oven.
*Note: The OVEN indicator light on the electronic display will turn ON and OFF when using the Bake feature and
during preheat. This is normal and indicates that the oven is cycling to maintain the selected baking temperature. When
the preheat indicator light turns OFF, your oven is ready.
1. OVEN INTERIOR LIGHT PAD— Used to turn oven interior light ON or OFF.
2. CLOCK SET PAD— Used to set the time of day.
3. COOK TIME PAD— Used to enter the length of the baking time.
4. CLEAN PAD— Used to select the Self-Cleaning cycle. A 2, 3 or 4 hour Self-Clean time may be selected.
5. TIMER PAD— Used to set or cancel the minute timer. The minute timer does not start or stop cooking. Also, TIMER pad is
used to set the Continuous Bake feature.
6. DELAY START PAD— Used to set the desired start time for baking & Self-Clean. May be used with COOK TIME to
program a delayed bake or clean cycle.
7. UP ARROW PAD— Used along with the function pads to select oven temperature, cook time, start time (when
programming an automatic start time), time of day, clean time and minute timer.
8. BAKE PAD—Used to select the bake function.
9. BROIL PAD— Used to select the variable broil function.
10. DOWN ARROW PAD— Used along with the function pads to select oven temperature, cook time, start time (when
programming an automatic start time), time of day, clean time and minute timer.
11. STOP PAD— Used to clear any function previously entered except the time of day and minute timer. Press STOP to stop
cooking. Also the STOP pad is used to activate oven lockout setting.
12. WARM PAD— Used to set the Warm & Hold feature.
13. OVEN, PREHEAT & DOOR LOCKED LIGHTS* — The “OVEN” light will glow each time the oven turns on to maintain the
set oven temperature. The “PREHEAT” light will glow when the oven is rst set to operate, or if the desired temperature
is reset higher than the actual oven temperature. The “DOOR LOCKED” light will ash when the oven door locks and
unlocks or when using the Self-Clean cycle or the oven door lockout is activated. The indicator light will glow constantly
after the door locks.
1
4
5 6
10 11 12
13
2 3 7 8 9
