CONTROL PANEL FEATURES
For complete details on button functions, see pages 22–24.
20
LCD DISPLAY
The LCD display shows the temperature
settings, dispenser options, and the water filter,
door alarm, and locking status messages. The
display can be switched into Power-Saving Mode
where it will only illuminate when a compartment
door is opened or a button is pressed.
1
CUBE/CRUSH BUTTON
The CUBE/CRUSH button is used to select
Cubed Ice or Crushed Ice.
2
FREEZER BUTTON
Press the FREEZER button to adjust the
temperature in the freezer compartment.
NOTE: When pressed simultaneously with the
REFRIGERATOR button for more than five
seconds, the temperature display will change
from Fahrenheit to Celsius or vice versa.
3
REFRIGERATOR BUTTON
Press the REFRIGERATOR button to adjust the
temperature in the refrigerator compartment.
NOTE: When pressed simultaneously with the
FREEZER button for more than five seconds,
the temperature display will change from
Fahrenheit to Celsius or vice versa.
4
ICE PLUS
Press this button to turn on the ICE PLUS.
feature, which increases icemaking capabilities
up to about 20 percent.
5
LOCK BUTTON
Press this button to lock or unlock all the other
function buttons on the control panel, including
operation of the dispenser.
8
FILTER RESET BUTTON
The FILTER RESET button resets the water filter
replacement indicator when the water filter has
been replaced.
9
LIGHT BUTTON
The LIGHT button controls the lamp in the
dispenser.
7
DOOR ALARM BUTTON
Press this button to control the door-open alarm.
6
CUBE/CRUSH
FREEZER
REFRIGERATOR
ICE PLUS
DOOR ALARM
LIGHT
LOCK 3SECS
FILTER RESET
