© 2007 by Stephen Beck V1.0 Page 6 of 19 Use at your Own Risk
8. Have your helper hold the frame while you unplug the small wire connector (Fig 2) from the PCB. This will
stop the power from going to the door flapper and ice dispenser.
9. Re-assemble the front door frame by hooking it to the top and gently pressing it back into place.
10. Replace the 2 screws to keep it from popping off.
11. Replace the drip tray
12. Plug the fridge back in. If the ice door flapper is in the open position, stick a CLEAN (white preferred, color
choice your decision) sock into the opening to prevent cold air from escaping.
© 2007 Stephen Beck
Fig. 2
Power to flapper door
and water dispenser
View looking down from the top
of the ice/water dispenser
