example, to block all computers with IP addresses starting with
“207”, enter “207.*.*.*” in the edit box and click enter. Note that
you can either block all addresses in the list or allow access only
to addresses in the list. This is controlled by the IP filter radio
buttons in the IP filter dialog or on the General tab of the
Configure dialog.
Depending on the DHCP process employed, IP addresses may
be filtered to limit the access to the FTP server. If the DHCP
process assigns a special group of IP addresses to the CM500
IPs, then this group can be filtered so as to be only group allowed
access to the server.
Additionally, if the filter mode is set to block listed addresses,
you can add a currently connected user to the IP filter list by
right-clicking on the user address in the user pane and selecting
Ban from the User Context menu.
Figure 9-10 User Context Menu
The user context menu allows you to select options for a
particular user, get information about the user, disconnect or ban
the user from the FTP server.
The user context menu is displayed by right clicking on a user
address in the user bar and supports the following commands:
Monitor: Enables/disables activity monitoring for the selected
user. User activity is displayed in the monitor window.
Keep file list: Maintains a memory list of files accessed by the
user.
Show file list: Outputs the list of files accessed by the selected
user if “Keep file lists” is on.
Show user info: Displays user information such as logon name,
password, time connected, last activity, etc. in the user info
window.
