Chapter 4
PC-IP Operation
57
Getting Information from the Install Profiler
To download database configuration Setup information (Figure
4-29) from an Install Profiler to the PC-IP software, click on the
Load Data button. The Install Profiler information is not stored
to a file on disk, but only to active memory for use in downloading
the information to other Install Profilers.
The display will sequence through all of the configuration
screens automatically and download the current configuration
information from the Install Profiler into temporary files,
which will be used to completely configure another Install
Profiler. The CLONE feature produces multiple Install
Profilers with identical configurations.
Sending Information to an Install Profiler
To upload the information retrieved in the previous Load Data
operation, connect the second Install Profiler to the PC, and click
on the Write Data button. The sending process will take several
minutes, since all of the channel tables are sent. If only a few
channel table are used, it may be faster to send each of the
individual configuration Setup files.
When the process is complete, the Clone Utility window will
display a text message stating “Clone Complete”. Repeating the
Write Data process will program another Install Profiler.
