re m o v I n g t h e dr a W e r fr o n t
1. Pull the freezer drawer completely
open.
2. Tilt the lower basket forward and lift
to remove.
3. Loosen the four (4) screws
attaching the drawer
brackets to the drawer front
as shown below.
NOTE: Loosen the screws only
three to four turns. Do not
remove the screws from the
drawer front.
4. Lift the drawer front upward
and off the screws.
re I n S t a l l I n g t h e
dr a W e r fr o n t
1.Slidethescrewsonthebackofthedrawerfrontintotheslots
in the drawer brackets on both sides. You may need to move the
bottom of the bracket around slightly to get the slot to line up with
the screw.
2. Tighten the four front panel screws completely. Do not over-
tighten.
3. Place the freezer basket back onto the drawer slides.
To Remove:
• Turn off ice maker by rasing the ice maker arm (see page 6).
• Pullupperbasketouttofullextensionandliftouttoremove.
To Install:
• Slideupperbasketintofreezer.Makesurethatrearofbasket
hooks behind rail catch.
ac c e S S o r I e S
Ice Bin
The ice bin provides storage for ice.
Lower Basket Divider
The lower basket divider allows the option to organize the basket
area into sections.
To remove and replace divider:
• Toremove,pulldividerstraightup.
• Toinstall,hooktopcornersofdividerovertophorizontalbasket
rungs.
re f r I g e r a t o r co m p a r t m e n t
fr e e z e r co m p a r t m e n t
ac c e S S o r I e S
Wine Trivet/Can Rack
The Wine Trivet/Can Rack accessory
fits in the Deli Drawer or on a shelf.
Bottles or cans can be laid crosswise,
or a single bottle may be laid in the
center depression.
up p e r WI r e ba S k e t
Deli Drawer Tray
The Deli Drawer tray allows for a removable tray within the full-
width storage drawer.
