Ic e a n d Wa t e r
au t o m a t I c Ic e ma k e r
Connect the ice maker to the water supply as instructed in the
installation instructions. Proper water flow and a level refrig-
erator are essential for optimal ice maker performance.
Operating Instructions
• Confirmicebinisinplace
and ice maker arm is down.
• Afterfreezersectionreaches
between 0° to 2°F (-18° to
-17° C), ice maker fills with
water and begins operating.
You will have a complete
harvest of ice approximately
every three hours.
• Allowapproximately24hours
after installation to receive first harvest of ice.
• Discardicecreatedwithinfirst12hoursofoperationtoassure
system is flushed of impurities.
• Stopiceproductionbyraisingicemakerarmuntilclickisheard.
• Icemakerwillremainintheoffpositionuntilarmispushed
down.
• Thefirstoneortwobatcheswillprobablycontainundersized
and irregular cubes because of air in the supply line.
• Whentheicecubesareejecteditisnormalforseveralcubesto
be joined together at the ends. They can easily be broken apart.
The ice maker will continue to make ice until the supply of ice
cubes raises the ice maker arm, shutting the ice maker off.
• Certainsoundsmayaccompanythevariouscyclesoftheice
maker. The motor may have a slight hum, the cubes will rattle
as they fall into an empty storage pan and the water valve may
click or “buzz” occasionally.
• Iftheiceisnotusedfrequently,theicecubeswillbecome
cloudy, shrink, stick together and taste stale. Empty the ice
storage bin periodically and wash it in lukewarm water. Be sure
to dry the bin thoroughly before replacing it.
• Beveragesandfoodsshouldnotbeplacedintheicestorage
binforquickchilling.Theseitemscanblocktheicemakerarm,
causing the ice maker to malfunction.
• Turnoff(armup)theicemakerwhenthewatersupplyistobe
shut off for several hours.
To Remove the Ice Bin:
• Pullitforward,awayfromtheicemaker.Toavoidtheicemaker
dumping ice while the bin is removed, turn the ice maker off by
raising the ice maker arm.
To Install the Ice Bin:
• Reversetheaboveprocedure.Turntheicemakeronby
lowering the ice maker arm.
Water Dispenser
The Water Dispenser is located on the left side wall of the fresh
food section. This design is for cold water dispensing only.
To Dispense Water:
• Holdcontainerunderspoutandpressdispenserpad.
