MERLIN LEGEND Communications System Release 6.0
System Programming
555-660-111
Issue 1
February 1998
Programming Procedures
Page 4-207PRI Facilities
4
Summary: Dial Plan Routing 4
Programmable by System Manager
Mode Hybrid/PBX
Idle Condition Not required
Planning Form Form 3b, Incoming Trunks: DS1 Connectivity (100D module)
Factory Setting Service: empty; Patterns: blank; Total Digits: 0;
Delete Digits: 0; Add Digits: 0
Valid Entries Service: Toll, Local, Miscellaneous
Entries: 0–15
Digits per Pattern: 0–8
Total Digits: 1–14
Delete Digits: 0–14, 0=wildcard
Add Digits: 0–4 (valid digits: 0–9)
Inspect No
Copy Option No
Console Procedure To specify Service:
→ → → →Dial entry
no.
→ →Select service→ → →
To specify Patterns:
→ → → →
Dial entry no.→ →Drop→Dial pattern→ →
→ →
To specify Total Digits:
→ → → →
Dial entry no.→ →Drop→Dial digits→ →
→ →
To specify Delete Digits:
→ → → → Dial
entry no.
→ →Drop→Dial delete digits→
→ → →
To specify Add Digits:
→ → → →
Dial entry no.→ →Drop→Dial add digits→ →
→ →
PC Procedure To specify Service:
→ → → →Type entry no.→ →
Select service
→ → → →
To specify Patterns:
→ → →
Type entry no.
→ →
+
→
Type pattern→ → → →
