Command Line Interface (CLI) AP-700 User Guide
Parameter Tables
209
IP Access Table Parameters
When creating table entries, you may either specify the argument name followed by argument value or simply enter the
argument value. When only the argument value is specified, then enter the values in the order depicted by the following
table. CLI applies default values to the omitted arguments. Due to the nature of the information, the only argument that
can be omitted is the “comment” argument.
Filtering Parameters
Ethernet Protocol Filtering Parameters
Ethernet Filtering Table
Identify the different filters by using the table index.
NOTE: The filter Operation Type (passthru or block) applies only to the protocol filters that are enabled in this table.
Static MAC Address Filter Table
Name Type Value Access CLI Parameter
IP Access Table Table N/A R mgmtipaccesstbl
Table Index Integer User Defined N/A index
IP Address IpAddress User Defined RW ipaddr
IP Mask IpAddress User Defined RW ipmask
Comment (optional) DisplayString User Defined RW cmt
Status (optional) Integer enable (default)
disable
delete
RW status
Name Type Value Access CLI Parameter
Ethernet Filtering Group N/A R etherflt
Filtering Interface
Bitmask
Interface Bitmask 0 or 2 = No interfaces
(disable)
1 or 3 = Ethernet
4 or 6 = Wireless
5 or 7 = All interfaces
(default is 7)
RW etherfltifbitmask
Operation Type passthru
block
RW etherfltoptype
Name Type Value Access CLI Parameter
Ethernet Filtering Table Table N/A R etherflttbl
Table Index N/A N/A R index
Protocol Number Octet String N/A RW protonumber
Protocol Name (optional) DisplayString RW protoname
Status (optional) Integer enable (1)
disable (2)
delete (3)
RW status
Name Type Value Access CLI Parameter
Static MAC Address Filter
Table
Table N/A R staticmactbl
Table Index N/A N/A R index
