Bravetti 524-15B Mixer User Manual



63
REF. NO PART NO. DESCRIPTION QTY.
1 150395 524 ELECTRIC INPUT SHAFT - 17..........................................1
2 185641 COVER PLATE .........................................................................1
3 780015 1-3/4” SEAL PLATE ASSEMBLY..............................................1
A 355028 1-3/4” GREASE SEAL...............................................................2
4 320720 #60-2 RC x 20 PITCHES COMP...............................................1
5 332612 60 B 20 x 1-3/4” CHAIN COUPLING SPROCKET....................2
6 185480 3/8” SQ. KEY x 2”......................................................................2
7 332614 6020 CHAIN COUPLING COVER.............................................1
8 344023 3:1 HUB CITY GEARBOX.........................................................1
9 324016 5V-2 GROOVE 16.0” SF BELT SHEAVE..................................1
10 336022 SF 1-3/8” QD BUSHING............................................................1
11 185484 5/16” SQ. KEY x 2”....................................................................1
12 781001 ELEC. BELT SHIELD DOOR ASSEMBLY................................1
13 325106 5V-1060 V-BELT .......................................................................2
14 324009 5V-3 GROOVE 9.25” SF BELT SHEAVE..................................1
15 336031 1-7/8” SQ BUSHING .................................................................1
16 185485 1/2” SQ. KEY x 2-1/2”................................................................1
17 850149 524 ELEC BELT SHIELD WELDMENT ....................................1
18 872003 ELEC. BELT SHIELD SUPPORT WELDMENT........................1
19 850147 524 ELEC. MOTOR BASE WELDMENT 25-50 ........................1
20 185087 ELEC. MOTOR PIVOT PIPE 24” ..............................................1
21 340228 VCJT 1-3/4” 2-BOLT FLANGE BEARING.................................1
22 330825 80 B 25H RC SPROCKET ........................................................1
23 340439 RCJC 2-7/16” 4-BOLT FLANGE BEARING ..............................1
24 781037 INPUT BEARING MOUNT & SEAL ASSEMBLY ......................1
A 355039 CR-24287 2-7/16”ID SEAL........................................................2
524 STATIONARY DRIVE ASSEMBLY
