Bravetti 524-15B Mixer User Manual



67
REF. NO PART NO. DESCRIPTION QTY.
1 332612 60 B 20 x 1-3/4” CHAIN COUPLING SPRKT........................... 2
2 185480 3/8” SQ. KEY x 2”..................................................................... 3
3 320720 #60-2 RC x 20 PITCHES COMP.............................................. 1
4 340229 1-3/4” FX3W228U 2-BOLT FLANGE BEARING ...................... 3
5 183277 BEARING HANGER TRAILER UNIT ....................................... 1
6 341028 1-3/4” PABCO BKP28T-TP W/BRG......................................... 1
7 150386 524 DRIVELINE-147” ............................................................... 1
8 850136 524 TRAILER BEARING PLATE WELDMENT ........................ 1
9 185299 CARRIER BEARING ANGLE................................................... 1
10 780601 PTO SHIELD ASSEMBLY........................................................ 1
11 338030 W-2400 383399 DRIVESHAFT-540......................................... 1
12 338442 W-2400 019516 YOKE 1000 RPM........................................... 1
540 & 1000 TRAILER PTO DRIVELINE ASSEMBLY
4
8
4
10
2
2
3
2
4
5
7
11
12
9
6
1
