When “SET” is pressed the display shows the set-point memory that is cur
-
rently being used and its value. Eight set-point memories are available.
S
Access set-point selection
1. 25.0 Set-point 1, 25.0°C currently used
Press “SET” to select this memory and access the set-point value.
S
Access set-point value
C 25.00 Current value of set-point 1, 25.00°C
Press “UP” or “DOWN” to change the set-point value.
U
Increment display
C 30.00 New set-point value
Press SET to accept the new value. The bath begins heating or cooling to the
new set-point.
S
Store new set-point
Press “EXIT” and the bath temperature will be displayed again.
E
Return to the temperature display
24.73 C Bath temperature display
The bath heats or cools until it reaches the new set-point temperature. Turn off
the cooling to reach and control at higher temperatures.
When setting the set-point temperature be careful not to exceed the temperature
limit of the bath fluid.
To obtain optimum control stability adjust the proportional band as discussed in
Section 9.6.
15
4 Quick Start
