Appendix C
HP E1368A/69A/70A Error Messages
Table C-1 lists the error messages associated with the Microwave Switch
module programmed by SCPI. See the appropriate mainframe manual for a
complete list of error messages.
Table C-1. Microwave Switch Error Messages
No. Title Potential Cause(s)
-211 Trigger ignored Trigger received when scan not enabled. Trigger received after scan
complete. Trigger too fast.
-213 INIT ignored Attempted to execute an INIT command when a scan is already in
progress.
-224 Illegal parameter value Attempting to execute a command with a parameter not applicable to
the command.
1500 External trigger source
already allocated
Assigning an external trigger source to a switchbox when the trigger
source has already been assigned to another switchbox.
2000 Invalid card number Addressing a module (card) in a switchbox that is not part of the
switchbox.
2001 Invalid channel number Attempting to address a channel of module in a switchbox that is not
supported by the module (e.g., channel 99 of a multiplexer module).
2006 Command not supported
on this card
Sending a command to a module (card) in a switchbox that is
unsupported by the module.
2008 Scan list not initialized Executing a scan without the INIT command.
2009 Too many channels in
channel list
Attempting to address more channels than available in the switchbox.
2010 Scan mode not supported
on this card
Sending a command to a module (card) in a switchbox that is
unsupported by the module
2012 Invalid Channel Range Invalid channel(s) specified in SCAN <
channel_list> command.
Attempting to begin scanning when no valid channel list is defined.
2600 Function not supported on
this card
Sending a command to a module (card) in a switchbox that is not
supported by the module or switchbox.
2601 Channel list required Sending a command requiring a channel list without the channel list.
Appendix C HP E1368A/69A/70A Error Messages 79
