Cook Door
7-13
DOOR REMOVAL AND REPLACEMENT PARTS LIST (LEFT SIDE):
See Figure 4-3 & 4-7a.
ITEM
Part
Number
Description Used on Model(s)
1 T0538 TRAILING ARM GUIDE C3/AB, C3MULTI
1 C0538 TRAILING ARM GUIDE C3/C, C3/CMULTI
2 T0550 TRAILING ARM, RH C3/AB, C3MULTI
2 C0550 TRAILING ARM, RH C3/C, C3/CMULTI
3 T0529 INTERLOCK ACTUATOR BRACKET
C3/AB, C3MULTI
3 C0529-2 INTERLOCK ACTUATOR BRACKET C3/C, C3/CMULTI
4 T0534 INTERLOCK SWITCH BRACKET C3/AB, C3MULTI
4 C0534 INTERLOCK SWITCH BRACKET C3/C, C3/CMULTI
5 T0330 INTERLOCK SECONDARY SWITCH
C3/AB, C3MULTI
5 C0330 INTERLOCK MONITOR SWITCH C3/C, C3/CMULTI
6 C0330 INTERLOCK PRIMARY SWITCH C3/C, C3/CMULTI
7 T0516 DOOR HINGE BAR MOUNTING
BRACKET
C3/AB, C3MULTI
7 C0516 DOOR HINGE BAR MOUNTING
BRACKET
C3/C, C3/CMULTI
8 T0542 SPRING, TRAILING ARM C3/AB, C3MULTI
8 C0542 SPRING, TRAILING ARM C3/C, C3/CMULTI
9 T0535 DOOR SPRING BRACKET C3/AB, C3MULTI
9 C0535 DOOR SPRING BRACKET C3/C, C3/CMULTI
10 TC3-0186 BRACKET, SPRING, LEFT C3/AB, C3MULTI
10 C0186 BRACKET, SPRING, LEFT C3/C, C3/CMULTI
11 101450 10-32 X 3/8 PPH CRES C3/AB, C3MULTI
11 TBD M5 X 10 mm PPH, CRES C3/C, C3/CMULTI
