Cook Door
7-16
FIGURE 7 – 6b Door Removal and Replacement (Right Side)
K6K3K2
K6
K4 K5
DOOR REMOVAL AND REPLACEMENT (RIGHT SIDE)
1. TRAILING ARM
2. INTERLOCK ACTUATOR BRACKET
3. INTERLOCK SECONDARY SWITCH
4. INTERLOCK SWITCH BRACKET
5. SPRING, TRAILING ARM
6. CAM FOLLOWER ROLLER
7. CAM FOLLOWER ASSY
8. HELPER SPRING
1
2
4
3
6
7
8
