7-22
C3/AB AND C3MULTI DOOR ASSEMBLY PARTS: See Figure 4-9
Item
#
Part
Number
Description Used on Model(s)
6
T0190
SHUNT, DOOR
C3/AB and C3/Multi
7
T0254
PLSTIC COVER, DOOR
C3/AB and C3/Multi
8
T0426
SHUNT SUPPORT DOOR
C3/AB and C3/Multi
9
T0193
OUTER SKIN, DOOR
C3/AB and C3/Multi
10
T0507
PLATE, DOOR REINFORCING
C3/AB and C3/Multi
11
T0325
GASKET, SHUNT
C3/AB and C3/Multi
12
M0999
SCRE
W, #8
-
32 X 3/8 SS
C3/AB and C3/Multi
13
R7329
SCREW, TAPPING, #8
-
32 X ½ SS
C3/AB and C3/Multi
14
C0581
NAMEPLATE
C3/AB and C3/Multi
15
NA
NA
C3/AB and C3/Multi
16
T0360
INSULATION KIT
C3/AB and C3/Multi
17
T0267
HANDLE, DOOR
C3/AB and C3/Multi
18
3136
SCREW, CAP ¼
-
20 X .75 HEX SS
C3/AB and C3/Multi
19
M0417
WASHER, LOCK
C3/AB and C3/Multi
20
T0450
WASHER, FENDER
C3/AB and C3/Multi
21
T0350
SPACER
C3/AB and C3/Multi
22
T0508
BEARING AND BLOCK ASSY
C3/AB and C3/Multi
23
T0503
PIVOT
PIN AND BRACKET ASSY
C3/AB and C3/Multi
24
T0427
SHUNT, SUPPORT SHIM
C3/AB and C3/Multi
25
T0504
WASHER, NYLON 5/16
C3/AB and C3/Multi
26
T0505
SCREW, #8
-
32 X .88 PAN HD SS
C3/AB and C3/Multi
27
T0514
BLOCK ASSY, PIVOT, TRAILING
C3/AB and C3/M
ulti
28 T0558 SCREW, #8-32 X .38 FLAT HD SS C3/AB and C3/Multi
29
T0550
TRAILING ARM, ASSY LH
C3/AB and C3/Multi
30
T0500
TRAILING ARM ASSY RH
C3/AB and C3/Multi
