Microwave Circuit
9-12
WAVEGUIDE COMPONENTS PARTS LIST: See Figure 9-6
Item
#
Part
Number
Description Used on Model(s)
1 T0266 BLADE, STIRRER ALL
2 T0289 SHAFT, STIRRER C3/AB, C3MULTI
2 C0289 SHAFT, STIRRER C3/C, C3/CMULTI
3 T0290 HUB, STIRRER SHAFT C3/AB, C3MULTI
3 C0290 HUB, STIRRER SHAFT C3/C, C3/CMULTI
4 T0282 SPROCKET, STIRRER SHAFT, .125 BORE All
5 T0284 BELT, STIRRER MOTOR All
6 T0397 MOUNTING PLATE, STIR MOTOR C3/AB, C3MULTI
6 C0391 MOUNTING PLATE, STIR MOTOR C3/C, C3/CMULTI
7 T0283 SPROCKET, MOTOR, 4MM BORE All
8 100891 MOTOR, 6 RPM All
9 101550 SCREW, 4-40 X 5/8 PPH SS C3/AB, C3MULTI
9 TBD SCREW, M3 x 12 mm SS C3/C, C3/CMULTI
10 102370 WASHER, SPLIT LOCK #4 SS C3/AB, C3MULTI
10 TBD WASHER, SPLIT LOCK M4 SS C3/C, C3/CMULTI
11 101590 SCREW, 6-32 X 3/8 PPH SS C3/AB, C3MULTI
11 TBD SCREW, M4 x 8 MM SS C3/C, C3/CMULTI
12 102380 WASHER, SPLIT LOCK #6 SS C3/AB, C3MULTI
12 TBD WASHER, SPLIT LOCK M4 C3/C, C3/CMULTI
13 102035 PIN CONNECTOR C3/AB, C3MULTI
14 102716 CONNECTOR HOUSING C3/AB, C3MULTI
15 102270 WASHER, INTERNAL LOCK, #6 SS C3/AB, C3MULTI
