Chapter 12 Routine operation
Page 12.10
12.11 Printed reports
The two types of report
The 795x can print out reports which give you information about the state of the system. There are two types
of report:
• Current report This shows the data currently stored in a list of up to 20 locations which you
specify.
• Alarm log report This shows the current contents of the alarm log, plus data from a list of up to 20
locations.
How to define a list of locations for reports
Find and note down the location IDs for all parameters you want to include in the list. (If you are unsure how to
find location IDs, it is explained in the section on configuring Multiview.)
NOTE: If you have more than one 795x, it is advisable to include the Unit ID in the
report list so that you know which instrument the report refers to.
Use the five-page menu shown in the diagram to define your list. Note that your list can include up to 20
locations.
V
a
b
c
d
a
b
c
d
V
Print reports
V
a
b
c
d
Print report
Current list
V
Location 7
Location 8
Location 5
a
b
c
d
V
Location 3
Location 2
Location 4
Location 1
a
b
c
d
V
a
b
c
d
V
a
b
c
d
Location 11
Location 12
Location 9
Location 15
Location 14
Location 16
Location 13
V
a
b
c
d
Location 19
Location 18
Location 20
Location 17
Options a and b each
go to identical 5-page
menus to define the lists
(Report type)
Alarm list
Define lists
Figure 12.2 Defining lists and printing reports
