CHAPTER 1 PRODUCT HANDLING AND SPECIFICATIONS
1.3 General Specifications
Table 1.3-1 "General specifications" lists the general specifications of the emulation
pod.
■ General Specifications of the Emulation Pod
Using the emulation pod at an ambient temperature or humidity
outside the specified range may cause a device failure. Always use the
emulation pod within the specified temperature and humidity range.
Table 1.3-1 General specifications
Item Specification
Name F
2
MC-16L/16LX/16F emulation pod
Model MB2145-507
Power Emulator power Voltage: +5V 5%
User system
power
Voltage: +1.8 V to 5.5 V
(*1)
Current consumption: 40 mA (maximum)
(*2)
Operating frequency 8 KHz to 20 MHz
(*1)
(machine clock frequency)
Operating temperature 5 to 35
Operating humidity 30% to 80% (no condensation)
Cabinet dimensions 158 mm (W) x 126 mm (D) x 38 mm (H)
Weight 500 g
*1: The upper limit and lower limit depend on the evaluation MCU used.
For details, contact the Fujitsu sales division.
*2: Current consumption for the evaluation MCU is not included.
CAUTION
Caution
