43
CVHE-SVU01E-EN
Operator
Interface
Display Settings
Description Units notes
1. Date Format (“mmm dd, yyy”, “dd-mmm-yyyy”), “mmm dd, yyy”
2. Date 4
3. Time Format (12-hour, 24-hour), 12-hour
4. Time of Day 4
5. Keypad and Display Lockout (Enable, Disable), Disable 5
6. Display Units (SI, English), English
7. Language (English, Selection 2, Selection 3), English 6
(1) Temperatures will be adjustable to 0.1 degree F or C. The Main Processor provides the minimum and maximum allowable value.
(2) Adjustable to the nearest whole number percent. The Main Processor provides the minimum and maximum allowable value.
(3) Terminates with 10 minutes if inactivity
(4) The Date and Time setup screen formats deviate slightly from the standard screens defined above. See the time and date section for further details.
(5) Enables a DynaView
™
Lockout screen. All other screens timeout in 30 minutes to this screen when enabled. The DynaView
™
Lockout Screen displays a 0-9 keypad to
permit the user to exit the lockout with a fixed password (1-5-9 + Enter). See lockout setion for further details.
(6) Language choices are dependent on what has been setup in the Main Processor. Language selections will include English and qty 2 alternate as loaded by TechView
™
.
Language shall always be the last setting listed on the Display Settings menu. This will allow a user to find language selection if looking at an unrecognizable language.
(7) Manual Compressor Control allows an operator to override the Auto Control and manually control the compressor while in operation. This is not active during Stop
mode.
Purge
Description Units Default
1. Purge Operating Mode (Auto, On, Adaptive, Stop), Adaptive
2. Daily Pumpout Limit Minutes
3. Disable Daily Pumpout Limit Hours
4. Purge Liquid Temperature Inhibit (Enable, Disable), Enable
5. Purge Liquid Temperature Limit Temperature
