Introduction
2
Oven Description and Specifications
Blodgett Deck ovens have set industry wide stan-
dards of excellence for baking characteristics,
performance and reliability. They remain unsur-
passed for product quality.
Simplicity of design and quality construction
throughout assure years of trouble free service
when the equipment is properly installed and
maintained.
Features include a full angle iron frame, all welded
radius corners and stainless steel fronts and
doors.
Natural Gas Propane Gas
US Units SI Units US Units SI Units
1060 -BL GAS SPECIFICATIONS
Heating Value 1000 BTU/hr 37.3 MJ/m
3
2550 BTU/hr 95.0 MJ/m
3
Specific Gravity (air=1.0) 0.63 0.63 1.53 1.53
Gas Manifold Pressure 3.5” W.C. 0.87 kPa 10” W.C. 2.49 kPa
Oven Input
Per Burner
Per Oven
42,500 BTU/hr
85,000 BTU/Hr
12.4 kW
24.9 kW
42,500 BTU/Hr
85,000 BTU/Hr
12.4 kW
24.9 kW
Main Burner Orifice Size 30 MTD* 3.3 mm 48 MTD* 1.93 mm
Pilot Burner Orifice Size .018” Dia. .46 mm .010” Dia. .25 mm
1060 -B GAS SPECIFICATIONS
Heating Value 1000 BTU/hr 37.3 MJ/m
3
2550 BTU/hr 95.0 MJ/m
3
Specific Gravity (air=1.0) 0.63 0.63 1.53 1.53
Gas Manifold Pressure 3.5” W.C. 0.87 kPa 10” W.C. 2.49 kPa
Oven Input
Per Burner
Per Oven
60,000 BTU/hr
120,000 BTU/Hr
17.6 kW
35.2 kW
60,000 BTU/Hr
120,000 BTU/Hr
17.6 kW
35.2 kW
Main Burner Orifice Size 23 MTD* 3.9 mm 44 MTD* 2.18 mm
Pilot Burner Orifice Size .018” Dia. .46 mm .010” Dia. .25 mm
NOTE: *Multiple Twist Drill
Gas Specifications are supplied in both US and SI (International Standard) units.
