Installation
10
Plumbing and Electrical Connections
PLUMBING CONNECTIONS
WARNING!!
Plumbing connections must comply with
applicable sanitary, safety and plumbing
codes.
Water Connections
Water supply should meet the follow ing condi-
tions. Consult y our local water company before
installing the oven.
D Hardness of 4-6 grains per gall on (100ppm max)
D PH of 6.5 to 8.0
D Chlorideslessthan30PPM
1. Connect the cold water supply to the 3/4”
MGHT connection on the back of the oven
with the water line provided. Supply pressure
should be 30 to 75 psi (207 to 517 kPa) when
the steam solenoid is open. The water regula -
tor on the oven itself must be set to 15 psi (103
kPa) when the steam solenoid is open.
Drain Connections
1. Connect drain line to the 3/4” NPT drain con-
nection on t he back of the oven.
2. Route the drain line t o a floor drain. Allow a 1”
air gap between the drain line and the floor
drain.
NOTE: When the oven is stacked o n a proofer a
separate drain line s hould be installed. If
a second drain line is not possible, pro-
vide a vent opening in the drain line above
the oven drain connection. Be sure to pro-
vide enough drop so the oven drain will not
flood the proofer cabinet.
ELECTRICAL CONNECTIONS
Wiring diagrams are located in the right bodyside.
This oven is supplied for connection to a 120 volt
grounded circuit. The electric motor, indicator
lights and related switches are connected through
the 6’ electric supply cord found at the rear of the
oven.
NOTE: When the oven is installed with a proofer a
separate 120 volt grounded circuit will be
required.
WARNING!!
This appliance is equipped with three
pronggroundingtypeplugforyour
protection against shock hazard and
should be plugged directly into a properly
grounded three prong receptacle. DO
NOT cut or remove the grounding prong
from this plug.
THE BLODGETT OVEN COMPANY CANNOT AS-
SUME RESPONSIBILITY FOR LOSS OR DAMAGE
SUFFERED AS A RESULT OF IMPROPER INSTAL-
LA TION.
ELECTRICAL SPECIFICATIONS
Model Hz Volts Phase Amps Electrical Connection
(minimum size)
XR8-G 60 120 1 5 Cord set provided
