Section 9 Parts List
+ Available Separately
32
Parts List Models QS12 & QS24
DESCRIPTION PART
NUMBER
QS12
QTY.
QS24
QTY.
W ARR.
CLASS
REMARKS PARTS
UPDATE
BAR--RELEASE SHEET *QS24* 079930 2 2 103 137
BLOCK--GAGE PLATEN KIT 078095 4 4 103
BLOCK--TERMINAL--5P SCREW
W/JUMPERS
X79838 1 103 LEFT SIDE -- J8050000/UP (50HZ & 60HZ)
BLOCK--TERMINAL--5P SCREW
W/JUMPERS
X79839--23R 1 103 RIGHT SIDE -- J8050000/UP (60HZ)
BLOCK--TERMINAL--5P SCREW 079045 1 103 LEFT SIDE -- PRIOR TO J8050000
BLOCK--TERMINAL--5P SCREW 079045--23R 1 103 RIGHT SIDE -- PRIOR TO J8050000
BLOCK--TERMINAL--6P SCREW 076943 1 103
BOX A. --RELAY *QS12/QS24* (NEW) X74036 --SER 1 2 212 J9054573/UP -- 50HZ & 60HZ
FOR SERVICE -- USE X74036 --SER
143
CONNECTOR--MATE LOK 6 CIR--SKT 029248 2 4 103
SOCKET --084 OD/14 --20 AWG--STRIP 021625 9 18 103
HARNESS--WIRE (RELAY BOX) 074039 1 2 103
PCB A. --CONTROL X53512 --SER 1 2 212
PCB A. --CONTROL (BASE BOARD) X53319--SER 1 2 212
CHIP--SOFTWARE (VERSION 1.01)
X40788--SER
1 2 103
RELAY--30A--277V--12VDC 074041 6 12 103
+BRACKET ”E” RELAY 074040 6 12 103
STRAP A.GROUNDING *QS24* X74123 1 2 000
BOX A.--RELAY *QS12/QS24* (OLD) X79678 --SER 1 2 212 USE X74036 --SER IN ALL APPLICATIONS 122, 143
CONNECTOR--MATE LOK 6 CIR--SKT 029248 1 2 103
SOCKET --084 OD/14 --20 AWG--STRIP 021625 3 6 103
HARNESS--WIRE RELAY BOX *QS24* 078616 1 2 103 INTERFACE TO KEY PAD BOX
PCB A.-- CONTROL GRILL X48604 --SER 1 2 212 USE X74036 --SER
CHIP--SOFTWARE *QS24* CONTROL X40863 1 2 103
PCB A. --INTERFACE GRILL X49540 --SER 1 2 212 USE X74036 --SER
RELAY--SPDT--200/240 VAC 079690 3 6 103 J7100000 --J9054572 (for 1800 WATT heater) 122
STRAP A.GROUNDING *QS24* X74123 1 2 000
BOX A. --RELAY -- (OLD) X78757 1 2 212 USE X74036 --SER IN ALL APPLICATIONS 143
BOX A. --REMOTE KEY PAD *QS12 & QS24* X78579 1 2 212
BEEPER--WITH WIRE HARNESS *QS 078617 1 2 103
