Models QS12 & QS24 Parts List
DESCRIPTION PARTS
UPDATE
REMARKSW ARR.
CLASS
QS24
QTY.
QS12
QTY.
PART
NUMBER
PANEL A.-- SIDE LEFT NONE NOT AVAILABLE FOR REPLACEMENT --
SEALED
PANEL A.--SIDE RIGHT NONE UNIT TO PREVENT GREASE MIGRAT ION
PANEL--REAR *QS12* 079280 1 103
PANEL--REAR *QS24* 079044 1 103
PARTITION A. --GREASE X79944 1 1 103 Replaces X78402 137
GASKET --GREASE PARTITION 074154 1 1 000 J9101783/UP (CAN ADAPT TO EXISTING
MODELS)
147
PIN--L OCATING 078544 4 4 103
PIVOT A.--PLATEN COMPLETE *QS24 X78758-- SER 1 1 103
ARM--PLATEN *QS24* 078520 2 2 103
ARM--PLATEN LINKAGE *QS24* 079192 2 2 103
BEARING--CYL MOUNT *QS24* 079214 2 2 103
BEARING--LINKAGE ARM *QS24* 079213 2 2 103
BEARING--OPEN END NEEDLE *Q524* 078522 8 8 103
BEARING--OPEN END NEEDLE *Q524* 078523 2 2 103
BEARING--OPEN END NEEDLE *QS24* 078652 2 2 103
BEARING--PLATEN ARM PIVOT QS24 078541 2 2 103
CAP--BEARING PLATEN ARM *QS24* 078548 2 2 103
CYLINDER--GAS DUEL SEAL QS24 074313 2 2 103 REPLACES 079215
E--RING 3/4 077046 4 4 000
E--RING 3/8 038958 16 16 000
E--RING EXTERNAL 1/2 024908 16 16 000
HANDLE--PLATEN LIFT *QS24* 078592 1 1 103
LINKAGE--PIVOT UPPER *QS24* 078760 2 2 103
MOUNT --CYLINDER LIFT *QS24* 079193 1 1 103
PIN--LINKAGE ARM *QS24* 078664 2 2 103
PIVOT A.--PLATEN *QS24* X78759 1 1 103
PIVOT--PLATEN ARM *QS24* 078556 2 2 103
PLATE--PLATED LINKAGE PIVOT LH 078560 1 1 103
PLATE--PLATED LINKAGE PIVOT RH 078559 1 1 103
RETAINER --BEARING *QS24* 079191 2 2 103
ROD--LINKAGE 3/4 DIA *QS24* 079216 1 1 103 ROD W/GEAR UNIT
